Mastering the interpretation of a 12-lead ECG in the context of Congenital Heart Disease requires moving beyond standard adult “ischemia-centric” thinking. In CHD, the ECG is a map of hemodynamic stress, reflecting chronic pressure or volume overloads that have physically reshaped the myocardium.
1. The “Situs” and Axis Assessment
Before looking at hypertrophy, you must establish the heart’s position and internal arrangement.
- Dextrocardia: Look for global inversion in Lead I (negative P, QRS, and T waves) and a lack of R-wave progression in precordial leads.
- The Frontal Plane Axis: Extreme right-axis deviation (+180° to -90°) is a hallmark of many cyanotic lesions. Conversely, a “superior” left-axis deviation (negative QRS in II, III, and aVF) in a cyanotic infant strongly suggests an Atrioventricular Septal Defect (AVSD) or Tricuspid Atresia.
2. Chamber Enlargement Patterns
In CHD, we look for “pure” forms of hypertrophy that are rarely seen in acquired adult disease.
Right Ventricular Hypertrophy (RVH)
RVH is the most common finding in CHD (e.g., Tetralogy of Fallot, Pulmonary Stenosis).
- Pressure Overload: Characterized by a tall R wave in V1 (>7 mm) and a deep S wave in V6. You may see a “pure” R wave in V1 (no S wave), which is highly specific for severe RVH.
- Volume Overload: Look for an RSR’ pattern in V1 (incomplete RBBB). This is classic for an Atrial Septal Defect (ASD).
Left Ventricular Hypertrophy (LVH)
Often seen in Ventricular Septal Defects (VSD) or Patent Ductus Arteriosus (PDA).
- Katz-Wachtel Phenomenon: This is a classic CHD finding. Look for large, biphasic QRS complexes in the mid-precordial leads (V2–V4). This represents biventricular hypertrophy caused by a large left-to-right shunt.
3. The P-Wave: Atrial Clues
The atria often provide the first hint of the underlying defect.
- P-Pulmonale: Tall, peaked P waves (>2.5 mm in lead II). This indicates right atrial enlargement, common in Ebstein’s Anomaly or severe pulmonary hypertension.
- P-Mitrale: Notched, wide P waves in lead II or a deep terminal negative deflection in V1, indicating left atrial enlargement (e.g., Mitral Stenosis or large VSD).
4. Specific CHD “Signatures”
Certain defects have such distinct ECG patterns they are almost diagnostic:
| Defect | Primary ECG Finding |
| ASD (Secundum) | Right axis deviation + Incomplete RBBB (RSR’ in V1). |
| ASD (Primum) / AVSD | Superior Left Axis Deviation + RSR’ in V1. |
| Tricuspid Atresia | Left Axis Deviation + Right Atrial Enlargement + LVH (in a cyanotic neonate). |
| Tetralogy of Fallot | Right Axis Deviation + Severe RVH (tall R in V1) + “Sudden” transition to S-wave in V2. |
| Ebstein’s Anomaly | “Himalayan” P-waves (massive RA) + bizarre RBBB + short PR interval (WPW association). |
5. Transitioning to Adult CHD (ACHD)
As patients with CHD age, the 12-lead focus shifts from hypertrophy to arrhythmia and conduction delays.
- Post-Surgical Scars: Scars from atriotomies (like the Mustard or Senning procedures) create reentry circuits, leading to Intra-atrial Reentrant Tachycardia (IART).
- QRS Duration: In repaired Tetralogy of Fallot, a QRS duration >180 ms is a significant predictor of ventricular tachycardia and sudden cardiac death.
